The uTrust 3700F is a high‑performance contactless smart card reader designed for fast, secure, and reliable authentication across enterprise, government, and financial applications. It supports a wide range of contactless credentials and delivers exceptional performance in high‑traffic environments.
Markland is the exclusive APAC distributor for Hirsch products, ensuring regional availability and support.
Government: Public service systems, Citizen ID verification
Security: Access control systems, Secure facility entry
Commercial: Loyalty programs, Membership authentication systems
Modern design with optional stand base kit for ergonomic desktop use
Bi-color LED provides visual feedback for card detection and operation status
848 kbps support in ISO/IEC 14443 for maximum end-user acceptance
~10M hours MTBF ensures long-term, maintenance-free operation
CCID protocol support with Windows, Linux, macOS and Android for seamless integration with minimal administration
Can be used with standard PCs and workstations, with optional stand base kit and multiple certification compliance
Fully compliant with USB 2.0 Full Speed, USB-CCID, Microsoft® WHQL, CE, FCC, UL94, UL60950, RoHS2, REACH and WEEE standards
Engineered for quick and straightforward deployment, ensuring the protection of personal and corporate data while adhering to compliance and cybersecurity standards
Low power consumption of only 50mA for cost-effective and sustainable operation
Certified with RoHS2, REACH and WEEE for sustainable operations
Parameter | Details |
Host Interface | USB 2.0 CCID (USB 1.1/3.0 compliant) |
Communication Speed | 12 Mbps (USB 2.0 full speed) |
Supported Contact Card ICs | • MIFARE™ (Classic, Ultralight, Ultralight C, MIFARE PLUS, DESFire, DESFire EV1 2/4/8k), FeliCa™, Calypso, CD21, NFC Forum Tag types 1/2/3/4 |
Data Transfer Rate | 106, 212, 424, or 848 kpbs, depending on card IC |
Antenna | Integrated |
Driver and Software | |
PC/SC Driver | PC/SC Specification Ver. 2.01.14 for: • Windows® 7/8/10/11 (32 and 64 bit), Windows® Server 2008/2012/2016/2019, WindowsXP, • MacOS 10.9.x - 12.2.x, • Linux 2.6.x, and 3.x, 4.x, 5.x (32 and 64 bit), • Android 8.0 and higher |
Software | PC/SC API; CT-API (through wrapper on top of PC/SC); M-Card API (through wrapper on top of PC/SC) |
Operating Conditions | |
Power Supply | USB Bus-powered |
Power Consumption | 50mA, excluding card |
Dimensions(L x W x H) | 91x75x12 mm |
Weight | 44 g ± 5% |
MTBF | ~10M hours |
Connector | 1.5m USB cable with USB type A connecto |
Status Indicator | Bi-Color LED |
Certifications / Compliance | |
Systems/Standards | USB 2.0 Full Speed, USB-CCID, Microsoft® WHQL |
Regulatory/Environmental | CE, FCC, UL94, UL60950, RoHS2, REACH, WEEE |
