The ID BOX 221 is an ultra‑compact, multi‑function half‑page e‑passport reader designed for fast, accurate, and secure identity verification. As the smallest e‑passport reader, it delivers exceptional performance in space-limited environments, making it ideal for kiosks, self‑service terminals and counters.
With its ultra‑thin design, robust SDK support, firmware upgrade capability, and compatibility with Windows, Linux, MacOS, and Android, the ID BOX 221 provides a powerful and flexible platform for integrators building modern identity authentication solutions.
Markland is the exclusive APAC distributor for Elyctis products, providing regional sales and support across the Asia-Pacific region
Self-Service: Registration kiosks, Automated check-in
Retail: Vending machines, Identity verification
Travel: Airport check-in counters, Passenger processing
Hospitality: Hotels, Guest registration
Healthcare: Hospitals, Patient registration
The smallest e‑passport reader available, optimized for kiosks, terminals, and embedded systems.
Ensures fast, accurate capture and high‑quality imaging.
ICAO 9303‑compliant reading for global travel documents.
ISO/IEC 14443 Type A/B support with <1s read/write speed depending on card type.
Supports multilingual text extraction for diverse document types.
Auto‑trigger scanning when a document is inserted.
Ultra‑thin 139 × 72 × 22 mm form factor for tight installations.
Windows, MacOS, Linux, and Android support with CCID and PC/SC compliance.
| Parameter | details |
| Communication interfaces | USB 2.0 full speed (12 Mbps) |
| Temperature | In operation: 0°C to +50°C Storage: -40°C to +80°C |
| Resolution | 500 ppi |
| Physical Dimensions (LWH) | 139 x 72 x 22 mm |
| Communication | CCID compliant (Windows, MacOS, Linux) Custom CCID library (Android) PC/SC 2.01 compliant (Windows, MacOS, Linux) PC/SC .net wrapper (Windows) |
| Supported protocols(Contactless) | ISO 14443 Part 1 to 4, type A/B – T=CL and Mifare All Mifare products: Ultralight, 1K, 4K, Plus, DESFire EV1, Smart MX,… |
| The operating system is supported | Windows, Linux, Android |
